<< TCM1.0E & TCM2.0E >>
<< TCM1.0E & TCM2.0E >>
page: 17
SERVICE TRAINING
© Copyright reserved 2007 Philips Consumer Electronics Euroservice
PERSONAL NOTES:
PERSONAL NOTES:
Philips CL, Consumer Care, April 2008 slide 17
Dismantling step 1
Place the TV set upside down on a table top, using the foam bars
Remove the screws that secure the rear cover.
Be careful: Now the rear cover could be lifted but the SSB and power
supply panel(s) are mounted in the rear cover and still connected to the
LCD panel and other boards.
Turn the set now.
Place the TV set upside down on a table top, using the foam bars
Remove the screws that secure the rear cover.
Be careful: Now the rear cover could be lifted but the SSB and power
supply panel(s) are mounted in the rear cover and still connected to the
LCD panel and other boards.
Turn the set now.
