<< TCM1.0E & TCM2.0E >>
<< TCM1.0E & TCM2.0E >>
page: 5
SERVICE TRAINING
© Copyright reserved 2007 Philips Consumer Electronics Euroservice
PERSONAL NOTES:
PERSONAL NOTES:
Philips CL, Consumer Care, April 2008 slide 5
Range Overview
TCM1.0E 20PFL3403/10
26PFL3403/10
TCM2.0E 19PFL5403D/10
20PFL3403D/10
22PFL5403D/10
26PFL3403D/10
26PFL5403D/12
The xxPFL3403/10 models are Europe LCD platform designed for driving below
panels:
• 20” LPL (RGB TTL)
• 26” AUO (LVDS)
The main chip is from Mediatec (MTK8200 series) and supports below inputs:
• one analog RF (PAL B/G D/K I, SECAM B/G D/K L/L’)
• one SCART (CVBS & RGB)
• one CMP (YPrPb can support from 480i up to 1080i)
• one VGA
• one HDMI (can support 480i/p, 576i/p, 720p up to 1080i/p)
• one S-Video input
• one Headphone output
The xxPFL3403/10 models are Europe LCD platform designed for driving below
panels:
• 20” LPL (RGB TTL)
• 26” AUO (LVDS)
The main chip is from Mediatec (MTK8200 series) and supports below inputs:
• one analog RF (PAL B/G D/K I, SECAM B/G D/K L/L’)
• one SCART (CVBS & RGB)
• one CMP (YPrPb can support from 480i up to 1080i)
• one VGA
• one HDMI (can support 480i/p, 576i/p, 720p up to 1080i/p)
• one S-Video input
• one Headphone output
