Description of device
Adjusting ring (high-medium-low)
Brightness (function available with video activated)
Colour saturation (function available with video activated)
Auxiliary 1 (function available even when communication is not
active if the system allows it)
Auxiliary 2 / Porter call (blue LED)
Intercom call
Select receivers from 5÷8 (blue LED)
Activate/deactivate communication (blue LED)
Disable ring/Mute (red LED)
Panic (red LED)
Activate and select entry panel.
This function is available only when the line is free.
Door lock release (blue LED)
In systems designed to accommodate this signal, during a call
from an entry panel or in self-connection, the permanently lit
LED indicates that the door is open.
Buttons lock
Press and hold down button
for 3 seconds; the buttons will not respond to
pressure for 30 seconds to enable cleaning of the device.
If more than one button is pressed at the same time, or repeatedly by accident,
the buttons lock will be automatically activated for 10 seconds.
The buttons lock is cancelled if there is an incoming call.
Note: Only use soft, dry or slightly damp cloths to clean the terminal; do
not use any chemical products.
Standard functions
Answering a call
When there is a call, at the same time as it starts ringing, the master devices
will display the picture coming in from the entry panel.
To answer the call press button
.
To mute the audio to the entry panel press button
.
To open the door of the entry panel displayed, press button
.
To terminate the call press button
.
The call will be terminated automatically after 60 seconds.
Note: On some types of system the icon
will light up or a special icon
will appear on the screen that warns that the door is open.
Self-connection
To see the picture taken by the entry panel without activating audio commu
-
nication, press button .
Where there are several entry panels or video cameras connected to the
system, press button
again to show in succession the pictures taken by
these devices.
To start audio communication with the entry panel displayed, press button
.
Activating auxiliary commands
Buttons
and can be associated to auxiliary commands (switching on stair
light, opening gate, etc.).
The buttons are enabled when communication is active, button
can be active
even when there is no active communication if the system’s conguration
allows it.
Disabling ring tone
To disable the ring tone press button
, the relative LED comes on.
The ring tone will be disabled for all call types; consequently, the receipt of a
call from the entry panel will ONLY activate the video. To reactivate the ring
tone, press button
again.
Video toggle function
In systems with several receivers, when there is a call, the caller’s picture is
displayed only on those receivers congured as “MASTER”s.
To display the caller’s picture on a “SLAVE” receiver, press button
.
To enable audio communication press button
.
Intercom
Intercom calls
In systems with several receivers, select the number of the desired receiver in
order to make the call. Press button
(LED on) to be able to select receivers
from 5 to 8.
After selecting the desired receiver, the receiver that’s calling will emit a line
free tone, while the receiver being called will ring.
To answer the call press button
on the receiver being called.
Transferring a call
With an active communication, select the receiver you wish to transfer the
call to (the receiver that’s calling will emit a line free tone, while the receiver
being called will ring).
To answer the call press button
on the receiver being called.
Once audio connection is made with the desired receiver, press
to transfer
the call.
The receiver that receives the call can also transfer it.
Porter functions
Porter call notication
The porter can send a notication asking to be called back. The notication
is marked by LED Aux2 coming on
and remains active until the porter is
called back.
To call the porter press button
.
Porter call request
It is possible to send a notication to the porter asking to be called back. To send
the request to the porter press button
, the porter will receive a notication
with the number of the caller.
Panic button function
Press button
for at least 1”, the receiver will beep and the red LED will
come on.
The porter receives a “Panic” notication, along with the caller number, the
LED stays on until the porter makes contact with the receiver.
The “Panic” notication takes priority over all calls.
Alarm signalling
If an alarm device is connected to the receiver’s dedicated input, its activation
will cause an alarm notication to be sent to the porter and this signal will
be notied by the receiver in the form of an intermittent acoustic signal for
approximately 10”.
