There must be a ventilation space of at least 200 cm
2
in the
plinth and at the top of the unit.
q
Basically the principle applies: the larger the ventilation space,
the more energy-saving the appliance is in operation.
WARNING
Fire hazard due to dampness!
If live parts or the mains lead become damp this may cause short
circuits.
u
The appliance is designed for use in enclosed areas. Do not
operate the appliance outdoors or in areas where it is exposed
to splash water or damp conditions.
WARNING
Fire hazard due to refrigerant!
The refrigerant R 600a is environmentally friendly but flammable.
Escaping refrigerant may ignite.
u
Do not damage the piping of the refrigeration circuit.
WARNING
Fire hazard and danger of damage!
u
Do not place appliances emitting heat e.g. microwaves, toast-
ers etc. on the appliance!
u
Detach the connecting cable from the rear of the appliance,
removing the cable holder at the same time because other-
wise there will be vibratory noise!
After installation:
u
Remove all transit supports.
u
Dispose of packaging material.
u
Always see to good ventilation at the installation site.
4.3 Disposing of packaging
WARNING
Danger of suffocation due to packing material and plastic film!
u
Do not allow children to play with packing material.
The packaging is made of recyclable materials:
-
corrugated board/cardboard
-
EPS moulded parts
-
polythene bags and sheets
-
polypropylene straps
u
Take the packaging material to an official collecting point.
4.4 Connecting the appliance
NOTICE
Risk of damage to the electronic control system!
u
Do not use stand-alone inverters (conversion of d.c. to a.c./
three-phase) or energy saving plugs.
WARNING
Fire and overheating hazard!
u
Do not use extension cables or multiple socket outlets.
The type of current (alternating current) and voltage at the instal-
lation site have to conform with the data on the type plate (see
Appliance at a glance).
Connect the appliance only with a properly installed
socket outlet with earthing contact. The socket outlet
must be fused with 10 A or higher.
u
Check the electrical connection.
u
Clean the appliance .
u
Plug in the power plug.
4.5 Switching on the appliance
Put the appliance into operation about 2 hours before first loading
food to be frozen.
Do not load food to be frozen before the temperature display
reads -18 °C.
u
Press On/Off button
Fig. 2 (4)
.
w
The temperature display and the alarm button flash until the
temperature is sufficiently cold. If the temperature is above
0 °C, dashes flash. If it is below, the current temperature flash-
es.
5 Control
5.1 Brightness of the temperature dis-
play
You can adjust the brightness of the temperature display to the
light conditions of the room in which the appliance is installed.
5.1.1 Adjusting the brightness
The brightness is adjustable between h1 (no illumination) and
h5 (maximum luminosity).
u
To activate the setting mode: press the SuperFrost button
Fig. 2 (5)
for about 5 s.
w
The display indicates c.
w
The SuperFrost button flashes.
u
Using the Up setting button
Fig. 2 (3)
or Down setting but-
ton,
Fig. 2 (2)
, select h.
u
To confirm: briefly press the SuperFrost button
Fig. 2 (5)
.
u
To make the display brighter: press Up button
Fig. 2 (3)
.
u
To make the display darker: press Down button
Fig. 2 (2)
.
u
To confirm: press SuperFrost button
Fig. 2 (5)
.
w
The brightness is adjusted to the new value.
u
To deactivate the set-up mode: press On/Off button
Fig. 2 (4)
.
-or-
u
Wait for 5 minutes.
w
The temperature is indicated again in the temperature display.
5.2 Child proofing
The child-proofing function enables you to make sure that the
appliance is not inadvertently switched off by playing children.
5.2.1 Setting the child lock
u
To activate the setting mode: press SuperFrost button
Fig. 2 (5)
for about 5 s.
w
The display indicates c.
w
The button SuperFrost flashes.
u
Briefly press the SuperFrost button
Fig. 2 (5)
to confirm.
u
To switch on: Using the Up setting button
Fig. 2 (3)
or Down setting button
Fig. 2 (2)
, select c1.
u
To switch off: Using the Up setting button, freezer
compartment
Fig. 2 (3)
or Down setting button,
freezer compartment
Fig. 2 (2)
, select c0.
u
To confirm: press SuperFrost button
Fig. 2 (5)
.
w
When the child lock symbol
Fig. 2 (7)
shines, the child lock is
activated.
u
To deactivate the set-up mode: press On/Off button
Fig. 2 (4)
.
-or-
Control
4
