Falmec Iris Tulip 120 (600) S [21/68] For corner hoods without bar

4. CLEANING THE INSIDE OF THE APPLIANCE

The electrical parts or parts of the motor assembly inside the range hood must not be

cleaned using liquids or solvents.

Do not use abrasive products.

All the above operations must be performed after having disconnected the appliance from the

mains power supply.

WARRANTY

The new equipment is covered by warranty. The warranty conditions are provided by the

distributor.

The manufacturer is not liable for any inaccuracies in this booklet resulting from printing or

transcription errors. The manufacturer reserves the right to modify its products as it consid-

ers necessary or in the interests of the user, without compromising their essential safety and

operating characteristics.

FOR WALL-MOUNTED RUSTIC HOOD

WARNING: Failure to install the screws or fixing device in accordance with these instructions

may result in electrical hazards.

Step 1

- Rest the support batten (A-Fig. 1) against the wall at a height above the hob determined by

the sum of the values X+Y+265 mm.

- Use a spirit level to make sure it is perfectly horizontal and make 2 marks at the ends of the

batten where the 2 holes are to be drilled.

- Drill the holes, insert the two ø 8mm screw anchors and fasten the batten using the relevant

screws.

Step 2

- Hook the hood onto the support batten (Fig. 2).

Step 3

- Adjust the alignment of the hood using the screws on the brackets (Fig. 3). The upper screw

(B) is used to adjust the distance from the wall, and the lower screw (C) the vertical sliding

Step 4

- In order to prevent the hood from unhooking owing to pressure from underneath, fasten it

to the wall with a screw anchor and relevant screw inserted in the appropriate hole (Fig. 4).

FOR CORNER HOODS WITHOUT BAR

Step 1

- Undo the rear metric screw (A) and remove the motor from the bottom of the hood (fig. 1).

- Check the horizontal alignment with a spirit level and mark the 4 holes to be drilled.

- Drill the holes, insert 2 x 8mm dia. screw anchors and fix the hood in the desired position,

using 2 screws B fixed in the two slots in the top back panel (Fig. 5).

- Fit the safety screws C in the bottom back panels (Fig. 5).

Step 2

- After having fixed the hood, connect the flexible hose to the fume outlet hole and to the cir-

cular pipe fitting of the motor chamber.

- Replace the motor at the bottom of the hood and secure it with the rear metric screw (A)

(fig. 2).
