5
ENGLISH
• After you finish ironing set the (11) regulator
to the “min” position and the steam supply
regulator (3) to the off steam position.
• Pull the plug out of the socket and let the iron
cool down completely.
ATTENTION!
If during the operation steam is not constantly
supplied, check whether the temperature regu-
lator (11) is set properly.
ADDITIONAL STEAM RELEASE
Additional steam release function is useful when
ironing folds and can only be used at high ironing
temperatures (when the iron temperature regu-
lator (11) is set to “•••” or “max”).
• When the additional steam release button (5)
is pressed, steam will be vigorously released
from the openings in the iron sole.
Note: In order to avoid leakage of water from
steam openings, press the additional steam
supply button (5) with 4-5 sec. interval.
STEAM CHAMBER CLEANING
To prolong lifetime of the iron we recommend
cleaning the steam chamber, especially in the
regions with “hard” water.
• Fill the water tank (10) till the MAX mark (12).
• Put the iron on the base (8).
• Insert the power plug into the outlet.
• Set the temperature regulator (11) to the MAX.
temperature: “max” the (9) indicator will light
up.
• When the sole temperature (13) reaches the
desired temperature value, the (9) indicator
will go out, you can start cleaning of the iron
chamber.
• Unplug the iron, set the temperature regulator
(11) to the «MIN» position.
• Pull the plug out of the socket.
• Hold the iron above the sink, set and hold the
regulator (3) to the position – SELF CLEAN.
• Boiling water together with scale will be throw-
ing out from the openings in the iron sole
(13).
• Slightly sway the iron back and forth, until wa-
ter goes out of the water tank (10).
• Place the iron on the base (8) and let it cool
down completely.
• When the sole (13) cools down completely,
wipe it with a dry cloth.
• Before you take the iron for storing, make sure
that there is no water in the water tank (10) and
that the iron sole (13) is completely dry.
CARE AND CLEANING
• Before cleaning the iron, make sure that it is
turned off and has cooled completely.
• Wipe the iron's outer surface with a damp
cloth and then wipe dry.
• Sediment on the iron sole can be removed
with a cloth soaked in vinegar-water solution.
• After removing sediment, polish the sole with a
dry cloth.
• Do not use abrasive substances to clean the
sole and body of the iron.
• Avoid touching the iron sole with sharp metal
objects.
STORAGE
• Turn the temperature regulator (11) anticlock-
wise till MIN position, set the steam release
regulator (3) to the position - steam release
OFF position.
• Remove the power plug from the outlet.
• Open the water tank lid (2), turn over the iron and
drain any remaining water from the water tank (10).
• Close the lid (2).
• Set the iron vertically and allow it to cool com-
pletely.
• Store the iron vertically.
TECHNICAL CHARACTERISTICS
Power requirements: 230 V ~ 50/60 Hz
Power consumption: 1600 W
Specifications subject to change without prior
notice.
MINIMUM SERVICE LIFE - 3 YEARS
GUARANTEE
Details regarding guarantee conditions can be
obtained from the dealer from whom the appli-
ance was purchased. The bill of sale or receipt
must be produced when making any claim under
the terms of this guarantee.
This product conforms to the EMC-
Requirements as laid down by the
Council Directive 89/336/EEC and to
the Law Voltage Regulation (73/23
EEC)
