Door Beverage Rack (on some models)
This rack holds up to 5 cans.
The rack hangs from the sides of the
dairy bin.
To remove:
Empty the wine/beverage rack.
Holding the bottom of the dairy bin,
lift the front straight up, then lift up
and out.
To detach the rack from the dairy bin,
pull the rack’s side wires out of the holes
on each side of the dairy bin.
To replace:
Reattach the rack to the sides of the bin.
Engage the back side of the bin in the
molded supports on the door. Then push
down on the front of the bin. The bin will
lock into place.
11
QuickSpace
™
Shelf
This shelf splits in half and slides under itself
for storage of tall items on the shelf below.
This shelf can be removed and replaced or
relocated just like Slide-Out Spillproof Shelves.
On some models, this shelf can not be used
in the lowest position.
Slide-Out Spillproof Shelf
The slide-out spillproof shelf allows you to reach
items stored behind others. The special edges
are designed to help prevent spills from dripping
to lower shelves.
To remove:
Slide the shelf out until it reaches the stop,
then press down on the tab and slide the shelf
straight out.
To replace or relocate:
Line the shelf up with the supports and slide it
into place. The shelf can be repositioned when
the door is at 90° or more. To reposition the shelf,
slide the shelf past the stops and angle
downward. Slide shelf down to the desired
position, line up with the supports and slide
into place.
Make sure you push the shelves all the way
back in before you close the door.
Press tab and pull shelf
forward to remove
Removable Beverage Rack
The beverage rack is designed to hold
a bottle on its side. It can be attached
to any slide-out shelf.
To install:
Line up the large part of the slots on
the top of the rack with the tabs under
the shelf.
Then slide the rack back to lock it
in place.
1
2
