Instructions for the installer

11.INSTALLING THE APPLIANCE

11.1 Installing in kitchen units

Veneers, adhesives or plastic coatings on adjacent furniture should be

temperature-resistant (no less than 90°C). If they are not sufficiently

temperature-resistant, they may warp over time.

The appliance must be installed by a qualified technician and according to the

regulations in force.

Depending on the type of installation, this appliance belongs to class 2,

subclass 1 (Fig. A - Fig. B) or to class 1 (Fig. C).

It may be installed next to walls, one of which must be higher than the worktop,

at a minimum distance of 50 mm from the side of the appliance, as shown in

figures A and C relative to the installation classes.

Make sure that there is a minimum distance of 750 mm between the stoves of

the hob and any shelf that may be installed directly above it. If a hood is installed

above the hob, refer to the hood instruction manual to ensure the correct

clearance is left.

Built-in appliance (Class 2 subclass 1)

Free-standing appliance (Class 1)
