Instructions for the Installer

10 INSTALLATION INSTRUCTIONS

10.1 Before installation

Check that the input voltage indicated on the characteristics plate is the

same as the voltage of the power outlet you are going to use.

Open the drawer and take out all the accessories and remove the

packing material.

Attention! The front surface of the warming drawer may be wrapped in a

protective film. Before using the warming drawer for the first time,

remove this film carefully.

Make sure that the warming drawer is not damaged in any way. Check

that the drawer opens and closes correctly. If you find any damage,

contact the Technical Assistance Service.

The warming drawer should only be built-in in combination with those

appliances indicated by the manufacturer. If it is fitted in combination

with other appliances, the guarantee is no longer valid since it is

impossible to guarantee that the warming drawer will work correctly.

10.2 Installation

To build-in the warming drawer in combination with another appliance

there must be a fixed, interim shelf in the housing unit to support the

weight of both appliances.

The appliance to be combined with the warming drawer will be placed

directly on the latter without any need to have a separating shelf.

To build-in the appliance which is combined with the warming drawer,

follow the instructions set out in the respective instructions and fitting

booklet.

The relevant installation dimensions are indicated in mm in the

installation diagram. Proceed as follows:

1. Place the warming drawer on the shelf and slide it towards the interior

of the niche in such a way that it is centred and completely lined up with

the front of the unit.

2. Check that the warming drawer’s frame is properly levelled and is sitting

evenly on the shelf.

3. Open the drawer and fix the warming drawer to the sides of the unit

using the two screws provided.
