Factory-fi tted stainless steel legs.
Selected appliances are delivered with adjustable legs
already installed at the factory. These provide enough
clearance from the fl oor to allow easy cleaning underneath
the appliance. Castors are optionally available.
Pressure relief valve.
Inside freezers a vacuum is built up by air exchange
which causes resistance when the door is reopened.
The integrated pressure-relief valve compensates
this vacuum automatically and immediately – the doors
remain
easy to open.
Quality right down to the smallest detail
Liebherr freezers with fan-assisted and static cooling provide perfect refrigerating capacity for high demands. The temperature
can be set accurately between -14°C and -28°C. High-quality materials, optimised and highly efficient components and
top-quality workmanship guarantee a long life and provide optimum storage conditions for frozen products.
Energy-e cient hot-gas defrost system.
Defrost less often and faster: the appliance defrosts only
when required since the electronic control system
calculates the defrost cycles based on the compressor run-
time. Energy-e cient hot gas reduces the defrost time from
approx. 30 to only approx. 10 minutes – with a low rise
in temperature in the appliance. Positive for food quality:
food items do not have to be removed during the defrost
phase and are not exposed to unnecessary temperature
fl u c t u a t i o n s .
Freezers with fan-assisted and static cooling
Advantage of hot gas defrosting
The temperature rise is minimal
30 min
Electric defrosting
10 min
Hot gas defrosting
X_GTE_N_XX_XX_01_1506_05.indd 24 10.06.15 15:58
Tough inner liner.
The inner liner is moulded with large radii. It is easy to
clean and enables perfect hygiene. Liebherr uses polystyrol
in commercial quality. This material is food-safe, extremely
tough and durable.
Easy-to-use electronic controls.
The precision electronic controller with digital display and
membrane keyboard is easy to use – and just as easy to clean
because the hygienic panel is seamless and dirt-resistant. A
keyboard locking function prevents inadvertent readjustment
of values.
In case of temperature deviations, caused e.g. by a
door that is open, a visual and audible door alarm is activated
thus protecting the freezer contents.
Forced-air cooling (in NoFrost GGv).
The high-performance forced-air cooling system rapidly freezes
products and maintains a uniform temperature. Adjustable wire
shelves provide maximum fl exibility, e.g. when storing large
packages.
Static appliances with baskets.
The static plate-evaporator system ensures freezing capacity
close to the product but is above all simple and very reliable.
The baskets provided are an ideal solution for handling and
storing frozen products.
X_GTE_N_XX_XX_01_1506_05.indd 25 10.06.15 15:58
