19
Menu 03
Defrosting
= activating the defrost function manually
The appliance defrosts automatically.
If the door has been left slightly open for a long time, a layer of
frost or ice may form in the interior and on the cooling plate. The
defrost function can then be activated manually.
>
Menu 01
Setpoint
>
Menu 03
Defrosting
>
Start Defrosting?
No Ok
Press button to start defrosting or press the button to
cancel the procedure.
Menu 01
Setpoint
= setting the temperature
>
Menu 01
Setpoint
>
New Set: -- ° C
Current: -- ° C
The current temperature is then shown at the bottom of the display
and the required temperature is shown at the top.
Use button
to reduce the temperature = colder. Use
button
to increase the temperature = warmer.
Press the
button to accept the new setting or the button
to cancel the procedure without saving.
Menu 04
Programs
= preset storage programs
If the appliance is to be used for special purposes, dierent storage
programs can be set. The storage climate inside the appliance
will then be adjusted to the intended use (temperature, humidity).
The following programs are available:
P12 Frozen Food
Storage of frozen food in general
P13 Ice Cream
Long term storage of ice cream
P14 Ice Cream Scoop
Ready-to-eat ice cream
Setting the storage program:
>
Menu 01
Setpoint
>
Menu 06
Settings
>
Menu 05
Alarm
>
Menu 04
Programs
>
P12 Set -20°C
Frozen Food
Select the desired program by pressing the buttons and .
Press the
button to accept the new setting or the button
to cancel the procedure without saving.
Main menu
Press the button.
Use buttons
and to select one of the menu items.
Menu 01
Setpoint = setting the temperature
Menu 03
Defrosting = activating the defrost function manually
Menu 04
Programs = preset storage programs
Menu 05
Alarm = list of alarms
Menu 06
Settings = settings on the control electronics
GB
