Part Locations and Removal

UPPER FRONT PANEL REMOVAL:

Remove the four screws located just above the

loading door. Tilt the bottom of the panel out and lift

the panel up and away from the dryer.

LOWER FRONT PANEL REMOVAL:

Remove the lint drawer. Remove the four screws

located just below the loading door. Tilt the top of

the panel out and lift the panel up and away from the

dryer.

TOP COVER REMOVAL:

First remove the back guard, then pull top cover

toward the rear of the dryer and lift up.
