450262-1 www.amdry.com 7

TUMBLER ALIGNMENT:

Proper alignment is achieved by making the gap

between the tumbler and openings in the front and

rear bulkheads equal on all sides.

The front to bulkhead may be checked for accuracy

by using a thickness gauge. The rear gap is not

accessible. Marking the position of the rear wheel

brackets before removing the brackets will help in

replacing the tumbler back into it’s original position

when the wheel brackets are reinstalled.

Adjust the tumbler position by loosening the three

bolts and forcing the wheel assembly toward the

center of the dryer to raise the tumbler and to move

it away from the side. A large screwdriver can

provide the necessary leverage. Adjustment of the

front of the tumbler is made by equalizing the gap

on the top, bottom, left and right by moving the wheel

assemblies.

Below, both wheel assemblies must be moved

inward in order to move the tumbler straight upward.

EXAMPLES:

Below, both wheel assemblies must be moved to

the right in order to move the tumbler right. The left

wheel assembly must move a little more than the

right in order to lift the tumbler.
