Hoshizaki IM-21CNE [61/92] A copeland compressor
![Hoshizaki IM-21CNE [61/92] A copeland compressor](/views2/1322676/page61/bg3d.png)
57
Model
Ambient Temp. (°C) 10 21 32 38
Water Temp. (°C) 10 15 21 32
Cube Hole Diameter (mm) 5 (15) 5 (15) 5 (15) 5 (15)
IM-130WNE-23 Ice Production (kg/d) 90 (100) 91 (95) 90 (92) 87 (89)
Freeze Cycle Time (min) 17.6 (14.0) 17.9 (15.4) 18.6 (16.5) 19.5 (17.3)
Defrost Cycle Time (min) 3.2 (3.0) 2.7 (2.5) 2.2 (1.9) 2.0 (1.8)
Water Consumption (lit/h) 26.0 (31.8) 12.6 (19.3) 12.2 (13.9) 11.7 (13.6)
Electric Consumption (W) 610 650 700 720
Head Pressure [peak] (bar) 19.5 19.5 19.5 19.5
IM-100CNE Ice Production (kg/d) 85 (95) 83 (93) 73 (84) 65 (70)
Freeze Cycle Time (min) 25.6 (21.1) 28.5 (23.4) 33.6 (26.6) 38.0 (32.1)
Defrost Cycle Time (min) 4.9 (3.9) 2.7 (2.1) 1.9 (1.7) 1.9 (1.8)
Water Consumption (lit/h) 17.7 (20.8) 8.3 (9.9) 7.3 (9.1) 6.5 (7.7)
Electric Consumption (W) 555 570 630 640
Head Pressure [peak] (bar) 6.5 9.0 12.0 15.0
IM-100CNE-23 Ice Production (kg/d) 72 (79) 71 (77) 67 (70) 65 (70)
Freeze Cycle Time (min) 20.9 (16.5) 23.4 (19.5) 26.1 (22.6) 27.0 (22.6)
Defrost Cycle Time (min) 5.1 (5.0) 3.0 (2.6) 1.8 (1.7) 1.8 (1.7)
Water Consumption (lit/h) 20.8 (25.0) 9.9 (11.6) 9.3 (10.7) 9.0 (10.7)
Electric Consumption (W) 555 570 630 640
Head Pressure [peak] (bar) 6.5 9.0 12.0 15.0
IM-100CNE-21 Ice Production (kg/d) 90 (92) 85 (87) 62 (64) 60 (62)
Freeze Cycle Time (min) 14.9 (12.5) 16.8 (14.3) 24.7 (20.7) 25.7 (21.5)
Defrost Cycle Time (min) 3.5 (3.2) 2.7 (2.3) 2.0 (1.8) 1.9 (1.7)
Water Consumption (lit/h) 29.3 (33.9) 13.3 (15.3) 9.7 (11.5) 9.4 (11.2)
Electric Consumption (W) 555 570 630 640
Head Pressure [peak] (bar) 6.5 9.0 12.0 15.0
IM-100CNE
(60Hz)
Ice Production (kg/d) 88 (98) 85 (93) 75 (83) 70 (75)
Freeze Cycle Time (min) 23.9 (18.8) 26.2 (21.4) 32.6 (26.8) 35.0 (29.8)
Defrost Cycle Time (min) 5.6 (5.4) 4.3 (4.1) 2.0 (1.8) 2.0 (1.9)
Water Consumption (lit/h) 18.3 (22.3) 8.5 (10.2) 7.5 (9.1) 7.0 (8.2)
Electric Consumption (W) 610 630 650 660
Head Pressure [peak] (bar) 6.5 9.0 12.0 15.0
[a] COPELAND COMPRESSOR
Ice Production = Capacity when shipped from factory
Values for water-cooled models are for icemaking water only. Use a cooling tower for cooling water.
Cube Hole Diameter: 5mm (15mm) for -28, -23, -32 3mm (7mm) for -21 6mm for -Q ball ice (45mm dia)
5mm for -S star ice, -H heart ice 10mm for -LM, -LM103
Model
Ambient Temp. (°C) 10 21 32 38
Water Temp. (°C) 10 15 21 32
Cube Hole Diameter (mm) 5 (15) 5 (15) 5 (15) 5 (15)
IM-240NE Ice Production (kg/d) 230 (240) 210 (230) 195 (210) 170 (195)
Freeze Cycle Time (min) 15.9 (14.3) 19.5 (16.7) 21.6 (18.9) 25.3 (20.5)
Defrost Cycle Time (min) 4.1 (3.7) 2.4 (2.1) 2.0 (1.7) 1.8 (1.7)
Water Consumption (lit/h) 31.3 (34.1) 14.9 (17.2) 13.9 (15.7) 12.1 (14.7)
Electric Consumption (W) 1195 1270 1320 1450
Head Pressure [peak] (bar) 14.0 17.0 21.0 25.0
IM-240NE-23 Ice Production (kg/d) 185 (225) 175 (215) 165 (195) 155 (185)
Freeze Cycle Time (min) 14.6 (10.8) 17.1 (13.0) 19.0 (15.2) 20.3 (15.0)
Defrost Cycle Time (min) 3.9 (3.7) 2.5 (2.2) 1.8 (1.6) 1.8 (1.7)
Water Consumption (lit/h) 33.9 (42.6) 16.7 (21.2) 15.8 (19.3) 14.8 (18.5)
Electric Consumption (W) 1195 1270 1320 1450
Head Pressure [peak] (bar) 14.0 17.0 21.0 25.0
