Page 3/14
PART
NO
DESCRIPTION
PART
NO
DESCRIPTION
1
Wheel_200x50
32
End cap
2
Screw cup
33
Clamp
3
Stud-bolt
34
Front cover
4
Hexagonal head screw
35
Insulating gasket
5
Hexagonal head screw
36
Combustion chamber support
6
Round washer
37
Air outlet cover
7
Hex cap screw
38
Air outlet point
8
Hex cap screw
39
Turbulator
9
T40/T70
40
Turbulator support
10
Side screen
41
Air outlet grille
11
Upper screen
42
Protective grille
12
Bottom screen
43
Protective grille
13
Upper cover
44
Protective grille
14
Support
45
Foot
15
Lid
46
Support
16
Footing
47
Slider
17
Cleat
48
Undercarriage support
18
Tank support
49
Undercarriage axis
19
Foot support
50
Handle pull
20
Front/rear panel
51
Insulating plate
21
Front/rear panel
52
Bigger flue
22
Side panel
53
Outlet pipe
23
Combustion chamber cover
54
Exchanger support
24
Front crown
55
Inlet pipe
25
Rear crown
56
Inlet flange
26
Upper part A/B
57
Crown cover
27
Upper part A/B
58
Cover flap
28
Bottom part A/B
59
Basket
29
Bottom part A/B
60
Handle end cap
30
Smaller flue
61
Fan
31
Support
62
Tank
Содержание
- Fig t40 construction 2
- Round washer 3
- Description 5
- Part no 5
- Round washer 5
- C basic component parts of the heater include cylindrical combustion chamber made of acid proof sheet and heat exchanger fitted with turbulators heat of burned oil is absorbed by air which is ventilated by fan and passes through heat exchanger and combustion chamber some of the heat is transported outside through the flue in form of combustion fumes excellent capacity of the heaters compensates for the heat losses and minimizes them maximum air temperature at the outlet is 8 7
- C both inlet and outlet points are secured with protective screens outlet and inlet points should never be obstructed t range heaters require disposal of combustion fumes flue connection should be made of insulated tin pipes and the flue should be in vertical position 1m above the rooftop of the heated building chimney flue diameter cannot be inferior to the diameter of the heaters flue horizontal connection between the heater and flue should be slightly inclined and not longer than 2 meters flue can be fitted by means of elastic spiro pipes provided that the above requirements are met t range heaters are powered by voltage rating 220 v in case of heaters 7
- C the device is additionally equipped with safety thermostat set at 11 7
- C the temperature is controlled by means of a thermostat with the range of 6 7
- T range heaters are portable devices each t 40 is equipped with a fuel tank external tanks of any capacity may be used t 70 heaters are not equipped with fuel tanks and can be fuelled from any plastic or metal tank meeting technical requirements blower heater is used for producing air heated up to max temperature of 8 7
