Alto-Shaam 767-SK глух. дверь [2/2] Low temperature smoker oven

dimensions: H x W x D

exterior:

33-3/8" x 26-5/8" x 31-5/8"

(848mm x 676mm x 802mm)

interior:

20-1/8" x 22" x 26-1/2"

(510mm x 559mm x 673mm)

product\pan capacity

100 lb (45 kg)

maximum

volume maximum: 53 quarts (67 liters)

Full-size pans: gastronorm 1/1:

Nine (9) 20" x 12" x 2-1/2" (530mm x 325mm x 65mm)

Five (5) 20" x 12" x 4" (530mm x 325mm x 100mm)

Full-size sheet pans:

Up to Five (5)* 18" x 26" x 1" on wire shelves only

*additional shelves required

26-5/8" (676mm)

25-11/16" (651mm)

*31-

11/16" (804mm) - with optional 2-1/2" casters

*35-1/16" (890mm) - with optional 5" caster

*33-13/16" (858mm) - with optional 6" leg

33-3/8" (848mm)

with 3-1/2" casters*

28-5/8" (726mm)

Shown with

optional bumper

34-7/8" (886mm)

56-3/4" (1441mm)

Electrical

Connection

54-1/16" (1373mm)

11-5/8"

(295mm)

31-5/8" (802mm)

30-3/16" (767mm)

(electrical connection)

24-1/8" (612mm)

23-5/8" (600mm)

5-1/8" (130mm)

Cord Length

120V - 5 ft. (1524mm)

230V - 8 ft. (2438mm)

767-SK

low temperature SmoKer oVeN

options & accessories

Bumper, Full Perimeter

(not available with 2-1/2 casters) 5010371

Carving Holder, Prime Rib HL-2635

Carving Holder, Steamship (Cafeteria) Round 4459

Casters, Stem -

2 rigid, 2 swivel w/brake

5" (127mm) 5004862

2-1/2" (64mm) 5008022

Door Lock with Key LK-22567

Drip Pan with Drain 14831

Legs, 6" (152mm), Flanged (set oF Four) 5011149

Pan Grid, Wire — 18" x 26" pan insert PN-2115

Security Panel w/ Key Lock 5013936

Shelf, Stainless Steel, Flat Wire SH-2324

Shelf, Stainless Steel, Rib Rack SH-2743

Stacking Hardware 5004864

Wood Chips bulk pack - 20 lb (9 kg)

Apple WC-22543

Cherry WC-22541

Hickory WC-2829

Maple WC-22545

# 34 - 1 0/ 14

W164 N9221 Water Street • p.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.

PHONE

: 262.251.3800 800.558.8744

U.S.A./CANADA

FAX

: 262.251.7067 800.329.8744

U.S.A. ONLY

www.alto-shaam.com

D U E T O O N G O I N G P R O D U C T I M P R O V E M E N T , S P E C I F I C A T I O N S A R E S U B J E C T T O C H A N G E W I T H O U T N O T I C E .

P R I N T E D I N U .S .A .

weight

net: 197 lb (89 kg) ship: 225 lb (102 kg)

crate dimensions: (l x w x h)

35" x 35" x 41" (889mm x 889mm x 1041mm)

instaLLation reQuirements

— Oven must be installed level.

— The oven must not be installed in any area where it may

be affected by steam, grease, dripping water, extreme

temperatures, or any other severely adverse conditions.

— Appliances with casters and no cord or plug must

be secured to the building structure with a flexible

connector.

not Factory supplied.

cLearance reQuirements

back 3" (76mm)

top 2" (51mm)

each side 1" (25mm)

eLectricaL

voltage phase cycle/hz amps kW cord & plug

120 1 60 16.0 1.9 nema 5-20p

20a - 125v plug

208 1 60 16.0 3.3 no cord

240 1 60 13.0 3.0

or plug

230 1 50/60 12.2 2.8 cee 7/7

plug rated 250v

ch2-16p

plug rated 250v

bs 1363 (u.k. only)

plug rated 250v
