Operation manual

FCQG35~140FVEB + FCQHG71~140FVEB

Split system air conditioners

3P308371-1 – 11.2011

How to clean the suction grille

See ﬁgure 5

1 Open the suction grille (action 1 in the illustration).

Refer to procedure step 1 in "How to clean the air ﬁlter" on

page 3.

2 Detach the suction grille (actions 5 to 6 in the illustration).

First detach the 2 strings from the pins of the decoration panel.

Hold the suction grille open at 45 degrees and lift it upward to

unhook it from the decoration panel.

3 Remove the air ﬁlter (actions 2 to 4 in the illustration).

Refer to procedure step 2 in "How to clean the air ﬁlter" on

page 3.

4 Clean the suction grille.

Wash with a soft bristle brush and neutral detergent or water,

and dry thoroughly.

5 Install the air ﬁlter back in place (perform actions 2 to 4 in the

illustration in reverse order).

6 Reattach the suction grille by performing procedure step 2 in

reverse order (perform actions 5 to 6 in the illustration in reverse

order).

7 Close the suction grille by performing procedure step 1 in

reverse order.

How to clean air outlet and outside panels

■ Clean with soft cloth.

■ When it is difﬁcult to remove stains, use water or neutral

detergent.

Start-up after a long stop

■ Conﬁrm the following.

-Check that the air inlet and outlet are not blocked. Remove

any obstacle.

-Check if the earth is connected.

- Is there a broken wire somewhere? Contact your dealer if

there are any problems.

■ Clean the air ﬁlter and outside panels.

- After cleaning the air ﬁlter, make sure to attach it.

■ Turn on the main power supply switch.

- The control panel display lights when the power is turned on.

- To protect the unit, turn on the main power switch at least

6 hours before operation.

What to do when stopping the system for a long period

■ Turn on FAN OPERATION for a half day and dry the unit.

-Refer to the manual of the remote controller.

■ Cut off the power supply.

-When the main power switch is turned on, some wattage is

being consumed even if the system is not operating.

- The remote controller display will be switched off when the

main power switch is turned off.

■ Clean the air ﬁlter and the exterior. Be sure to replace the air

ﬁlter to its original place after cleaning. Refer to "Maintenance"

on page 3.

NOTE

When the suction grille is very dirty, use a typical

kitchen cleaner and let it sit for about 10 minutes.

Then, wash it with water.

Do not wash the suction grille with hot water of more

than 50°C. Doing so may result in discoloration and/or

deformation.

NOTE

Do not use gasoline, benzene, thinner, polishing

powder, liquid insecticide. It may cause discoloring or

warping.

Do not let the indoor unit get wet. It may cause an

electric shock or a ﬁre.

Do not scrub ﬁrmly when washing the blade with water.

The surface sealing may peel off.

Do not use water or air of 50°C or higher for cleaning

air ﬁlters and outside panels.
