REVERSE THE DOOR SWING

FOR BUILT-UNDER SERIES

Remarks:

•

Reversing the door is only available for a unit with 870mm height, and with control panel inside the cabinet.

•

The instruction is based on a unit with right door hinge installed already.

•

To reverse the door from right hinge to left hinge, you need to identify the 2 supplied spare parts: an

Upper

Left Hinge,

and a

Bottom Left Hinge

It is suggested that all spare parts are saved in case of door re-reversal.

-Open the door, and loosen the 2 screws from the support rod in the Lower Right Hinge.

-Carefully remove the door from the Upper Right Hinge and prevent it from scratching. Take out the

support rod from the door hinge hole.
