Installation Instructions

This section describes how to set up your fi re.

Before installing this appliance in an existing chimney, we recommend that;

1. You have your chimney cleaned by a competent chimney sweep.

2. You block off the chimney fl ue.

This procedure is important for the effi cient operation of the heating unit and will also reduce heat loss up the chimney.

BEFORE YOU START

1. Ensure that all packing items are removed (read any warning labels carefully) and retain all packing for possible

future use e.g. in the event of moving house or returning the appliance to your supplier.

1. Release the two red tabs by turning them by 90 degrees (see Fig 2)

2. Lift out the Sump Nozzle (Fig 3)

3. Insert lamps into lamp holders (Fig 4), carefully locating the pins into the holes (Fig 4a)

4. Push lamps fi rmly into place

5. Place the Transducer Unit into the sump and join the cable to the connector on the sump (Fig 5)

6. To ensure that the Transducer Unit is correctly placed in the sump, the tab on the Transducer Unit should be lined

up with the moulded recess in the sump (Fig 5a).

7. Ensure that the cable is not placed above the disc on the Transducer Unit (Fig 5b). To prevent the cable becoming

pinched between the nozzle and the sump, place the cable in the slot in the wall of the sump.

8. Replace the Sump Nozzle and secure it by turning the two red tabs by 90 degrees (Fig 6)

12. Place the Water Tank in the Sump, with the tank cap facing down and the fl at side of the tank facing outward (Fig 8)

Assembling the fi re

13. Place the Fuelbed on top of the Water Tank and Mist Nozzle (Fig 9)

Operating the Fire

This section describes how to activate your fi re using either the manual controls

MANUAL CONTROLS

The manual controls are located beneath the hinged fl ap underneath the fuelbed. Lift off the fuelbed and carefully

place aside. To access the controls lift up the fl ap. (See Fig.10 for Manual Control lay out)

Switch ‘A’:- Controls the electricity supply to the Fire.

Note: This switch must be in the ‘ON’ ( I ) position for the Fire to operate either with or without heat.

Press to put fi re in to standby mode. This will be indicated by one beep.

Control Knob ‘C’:- Controls the Thermostat setting.

Turning the control knob to the left will decrease the temperature setting, turning the control knob

to the right will increase the temperature setting.
