En-6

Intake grille

Instructions:

1. Pull the hinges and unhook the safety strings to remove.

• Wipe with a soft dry cloth, or wash it with water using soft cloth, sponge, etc.

• Do not soak it in water for more than two hours.

• Dry it well in shade before installing it.

Air cleaning ﬁ lter

(Anti-Allergy Enzyme Filter, option)

Back side of air ﬁ lter

• Clean every 3 months.

• Soak the ﬁ lter together with its frame in lukewarm water and wash it.

• After washing, dry it well in shade and put it back to its original position. Install

all tabs of the air ﬁ lter.

• Replace it with a new air cleaning ﬁ lter every year for best performance.

• Parts Number MAC-171FT-E

Air ﬁ lter (Catechin air ﬁ lter, option)

• Clean every 2 weeks

• Remove dirt by a vacuum cleaner, or wash with water.

• Dry it well in shade before installing it.

Install the tabs into the intake grille hole.

• Parts Number MAC-3004CF-E

CLEANING

• Switch off the power supply or turn off the breaker before cleaning.

• Be careful not to touch the metal parts with your hands.

• Do not use benzine, thinner, polishing powder, or insecticide.

• Use only diluted mild detergents.

• Do not expose parts to direct sunlight, heat, or ﬂ ames to dry.

• Do not use water hotter than 50°C.

1. Press

PUSH

indicated on the intake grille until a “click” is heard.

2. Install the intake grille by following the removal procedure in reverse.

Tabs

Note:

Clean the ﬁ lters regularly for best performance and to reduce power consump-

tion.

What is “Catechin air ﬁ lter”?

Catechin is a bioﬂ avonoid that is found in green tea that has both antiviral and

antioxidant qualities. In addition to these beneﬁ ts, Catechin also offers excel-

lent deodorizing characteristics. Catechin air ﬁ lter uses this compound to not

only improve air quality but also prevent the spread of bacteria and viruses in

the room.

Make sure to hook the safety string of the intake grille.

Not doing so may cause injury due to the intake grille falling.

WARNING

2. Hook your ﬁ ngers on the intake grille and pull down to open.

1. Close the intake grille. It will be temporarily ﬁ xed with magnets.

2. Press

PUSH

indicated on the intake grille until a “click” is heard.

3. Close the intake grille securely, pressing the three positions.

When the intake grille is not closed properly, open the intake grille and start

the procedure again.

Make sure that the safety strings do not hang outside of the intake grille.

Open Close
