Mitsubishi Electric PLFY-P32VCM-E [13/42] Error codes indication

Mitsubishi Electric PLFY-P15VCM-E [13/42] Error codes indication
13
GB
7.2. Error Codes indication
ON/OFF
ERROR CODE
If the ON lamp and error code are both flashing: This means that the air conditioner is out of order and operation has been stopped (and cannot
resume). Take note of the indicated unit number and error code, then switch off the power to the air conditioner and call your dealer or servicer.
Error Code
ON lamp
(Flashing)
ON/OFF
°C
°C
ERROR CODE
ON/OFF
CALL:XXXX
XXX:XXX
Error Code
8. Function Selection
Function selection of remote controller
The setting of the following remote controller functions can be changed using the remote controller function selection mode. Change the setting when
needed.
Item 1 Item 2 Item 3 (Setting content)
1. Change Language
(“CHANGE
LANGUAGE”)
Language setting to display • Display in multiple languages is possible
2. Function limit
(“FUNCTION
SELECTION”)
(1) Operation function limit setting (operation lock) (“LOCKING
FUNCTION”)
• Setting the range of operation limit (operation locking function)
(2) Use of automatic mode setting (“SELECT AUTO MODE”) • Setting the use or non-use of “automatic” operation mode
(3) Temperature range limit setting (“LIMIT TEMP FUNCTION”) • Setting the temperature adjustable range (maximum, minimum)
3.Operation mode
selection
(“MODE SELECTION”)
(1) Remote controller main/sub setting (“CONTROLLER MAIN/
SUB”)
• Selecting main or sub remote controller
* When two remote controllers are connected to one group, one
controller must be set to sub.
(2) Use of clock setting (“CLOCK”) • Setting the use or non-use of clock function
(3) Timer function setting (“WEEKLY TIMER”) • Setting the timer type
(4) Contact number setting for error situation (“CALL.”) • Contact number display in case of error
• Setting the telephone number
4. Display change
(“DISP MODE
SETTING”)
(1) Temperature display °C/°F setting (“TEMP MODE °C/°F”) • Setting the temperature unit (°C or °F) to display
(2) Suction air temperature display setting (“ROOM TEMP DISP
SELECT”).
• Setting the use or non-use of the display of indoor (suction) air
temperature
(3) Automatic cooling/heating display setting (“AUTO MODE DISP
C/H”)
• Setting the use or non-use of the display of “Cooling” or “Heating”
display during operation with automatic mode
7. Other Functions
When the Check button is pressed:
If you have entered contact number to be called in the event of a problem, the screen displays this number.
(You can set this up under Function Selection of remote controller. For information, refer to section 8.)
If only the error code is flashing (while the ON lamp remains lit): Operation is continuing, but there may be a problem with the system. In this case,
you should note down the error code and then call your dealer or servicer for advice.
* If you have entered contact number to be called in the event of a problem, push the Check button to display it on the screen. (You can set this up
under Function Selection of remote controller. For information, refer to section 8.)
Indoor Unit No.
