3.6. Ventilation

• The ventilation unit (OA processing unit or LOSSNAY) automatically goes into

operation when the indoor unit that is interlocked with it goes into operation.

• If the 8 [Ventilation] button is pressed while the indoor unit is stopped, only the

ventilator goes into operation.

• Press the 8 [Ventilation] button to change the fan speed.

• Depending on the models, the indoor unit fan goes into operation while the unit

is in the ventilation mode.

4. The smart way to use

Even minimal steps to care for your air conditioner can help make its use far

more effective in terms of air-conditioning effect, electricity charges, etc.

Set the right room temperature

• In cooling operation, a temperature difference of about 5 °C between indoors

and outdoors is optimum.

• If the room temperature is raised by 1 °C during air-cooling operation, about

10 % electric power can be saved.

• Excessive cooling is bad for health. It also results in the waste of electric power.

Clean the filter thoroughly

• If the screen of the air filter becomes clogged, the airflow and air-conditioning

effect can be significantly reduced.

Further, if the condition is left unattended, failure can result. It is particularly

important to clean the filter at the beginning of the cooling and heating sea-

sons. (When profuse dust and dirt have accumulated, clean the filter thoroughly.)

Prevent intrusion of heat during air-cooling

• To prevent the intrusion of heat during cooling operation, provide a curtain or a

blind on the window to block out direct sunlight. Also, do not open the entrance

or exit except in cases of dire necessity.

Carry out ventilation sometimes

• Since the air periodically gets dirty in a room that is kept closed for a long time,

ventilation is sometimes necessary. When gas appliances are used together

with the air conditioner, special precautions must be taken. If the “LOSSNAY”

ventilation unit developed by our company is used, you can perform ventilation

with less waste. For details on this unit, consult with your dealer.

5. Caring for the machine

Always have filter maintenance performed by a service person.

Before care-taking, turn the power supply OFF.

Caution:

• Before you start cleaning, stop operation and turn OFF the power supply.

Remember that the fan is rotating inside at high speed, posing a serious

risk of injury.

• Indoor units are equipped with filters to remove the dust of sucked-in air.

Clean the filters using the methods shown in the following sketches. (The

standard filter should normally be cleaned once a week, and the long-life

filter at the beginning of each season.)

• The life of the filter depends on where the unit is installed and how it is

operated.

How to clean

• Clear dust away lightly or clean it up with a vacuum cleaner. In the case of

severe staining, wash the filter in lukewarm water mixed with dissolved neutral

detergent or water, and then rinse off the detergent completely. After washing,

dry it and fix it back into place.

Caution:

• Do not dry the filter by exposing it to direct sunlight or warming it using

fire, etc. Doing so can result in the deformation of the filter.

• Washing it in hot water (more than 50

°C) can also result in deformation.

Caution:

Never pour water or flammable sprays onto the air conditioner. Cleaning using

these methods can result in the failure of the air conditioner, electric shock,

or fire.

3.7. Others

: Displayed when control is executed by a separately

sold centralized control unit, etc.

STAND BY

DEFROST

: Displayed from the start of heating operation until the

moment warm air blows out.

CHECK

: This displays indication when some abnormality oc-

curs in the unit.

NOT AVAILABLE

: When a Button is pressed for any function which the

indoor unit cannot perform, this display flashes con-

currently with the display of that function.

: In the system in which the [Sensor] display is indi-

cated as the “remote controller”, room temperature

measurement is performed by the room temperature

sensor built into the remote controller.

FILTER

: Displayed when it is time to clean the filter.

Press the A [FILTER (

)] Button twice, then the dis-

play is disappeared.
