- 10 -
Do not use water to clean electric box directly or soak the electric
box into water to clean.
Do not use old oil to fry because it will cause over boiling.
To fry over wet food and over add for one time will cause accident.
G. Troubleshooting
Troubles
Causes
Solution
1.Plug the machine
and get through
power supply ,power
indicator is not on
and heat
1. Plug is not inserted well.
2.Micro-switch contacts
not well
1. Remove the plug.
2.Adjust the limit
distance of
micro-switch
2. Heating indicator
is not on,
temperature is not
raised.
1. Connection of electric
heating tube is loosened.
1.Firm two sides of
electric heating tube
and screw
2.Change electric
heating tube
3. Power indictor is
on but the setting
temperature is not
raised
1. Temperature controller
is burned
1.Change temperature
controller
4.Temperature
control is normal but
indicator is not on
1. Indicator is burned.
1.Change indicator
5. After circuit
heating electric
heating tube is not
heated.
1. Temperature limiter
works.
1. Reset “over heating
protecting button” by
hand.
6. Temperature
control can not be
controlled.
1. Temperature limiter is
out of order
.
1. Change temperature
limiter
Aforementioned trouble are just for reference .If any fault occurs, please
cease using, return it to professional technicians for check and repair.
