- 4 -
C. Basic parameter
Name
Electric Fryer
Model
HDF 4
HDF 4+4
Voltage
220~240V,
50/60Hz
220~240V,
50/60Hz
Power
2500W
2*2500W
Number of oil
pot
1
2
Size of oil pot
186*270*170
186*270*170
The setting range
of temperature of
oil
60°C~190°C
60°C~190°C
Moving
temperature of
temperature
limiter
230°C
230°C
Dimension(mm)
445*285*360
445*495*360
Length of handle
(mm)
240
240
weight
5.6
10.2
Volume
4L
4L+4L
Number of
frying basket
1
2
THE QUANTITY OF FOOD FOR COOKING IN ONE TIME,
ACCORDING TO MEET, IT SHOULD NOT BE OVER 1.2KG PER
POT.
NOTE
THE QUANTITY OF FOOD WHICH IS NOT MAET MUST BE LIMITED IN
ORDER TO AVOID OIL OVERFLOWING.
TO FRY FOOD WHICH IS TOO WET AND TOO MUCH FOR ONE TIME
WILL CAUSE OIL BE OVERBOILING.
ACCORDING TO NOMARL.VOLUME TO ADD FOOD INTO EACH
FRYER.
OVER-WET AND TOO LARGE FOOD WILL EFFECT THE SURGE OF
BOILING OF OIL.
