VIOLETTA X / GIULIETTA X / ISETTA EVO / ISOTTA EVO / VIOLA EVO / ISOTTA FORNO

18 1195300

5. TECHNICAL DESCRIPTION

Denition: product according to EN 13240. The appliance works as an intermittent operating appliance.

The chimney stoves of La Nordica are suitable to heat living spaces for some periods or to support an insufcient centralized heating

system. They are ideal for holiday apartments and weekend houses or as an auxiliary heating system during the whole year. As fuel, it is

possible to use wood logs. The chimney stove is made of raw and enamelled meltings of cast iron.

The hearth is internally sheathed with single sheets in cast iron and inside it there is a turning and extractable grate. The model GIULIETTA

x, VIOLETTA x, is provided with an internal side of the hearth, which is extractable and pierced. Thanks to the calibrated holes of that side,

PRIMARY Air register (B Picture 6 at page 62)

With the thermostat (ISETTA EVO, ISOTTA EVO, VIOLA EVO) or valve (GIULIETTA x, VIOLETTA x) placed on the back of the right side

of the stove, it is adjusted the passage of air through the ash drawer and the grate in the fuel direction. The primary air is necessary for

the combustion process. The ash drawer must be regularly emptied, so that the ash does not obstruct the primary air entry. Through

the primary air the re is also kept alive.

During wood combustion, the register of primary air must be opened only for a while, because otherwise the wood burns fast and the

stove may overheat. For the correct arrangement (see paragraph NORMAL OPERATION).

SECONDARY Air register (A Picture 6 at page 62)

Over the door of the hearth there is the secondary air control.

This regulator must be open (the lever must be moved to the right), especially for wood combustion, so that unburnt carbon undergoes

LIGHTING OPERATION :

Open the secondary air register (A), primary air register (B), open the ignition control (C), light up the re.

After about 10 minutes, when the re is lighted, close the thermostat (B) and the ignition control (C) and adjust the combustion course

with the controls (A). The openings for air (primary and secondary) must be opened together just a little (you must open the eventual

buttery valve placed on the pipe of smokes exhaust). See chapter LIGHTING.

LOAD THE FUEL:

Before opening the hearth door, open the ignition control (C), load the fuel, close the door and after about 5 or 10 minutes close

the control (C). IMPORTANT: we suggest you to open the door very slowly, to avoid the exit of smokes.

The adjustment of the registers necessary to reach the rated caloric yield is the following one:

Mass of fuel hourly

CLOSED PRE-CALIBRATED

CLOSED PRE-CALIBRATED

ACCESSORIES

GIULIETTA x ISETTA EVO ISOTTA EVO ISOTTA FORNO VIOLA EVO VIOLETTA x

products and any condensation;

• there must be no narrowing and vertical passages with deviations must not be greater than 45°;

• if already used, it must be clean;

• the technical data from the instruction manual must be respected;

If the ues are of a square or rectangular section, the internal edges must be rounded with a radius of not less than 20 mm.

For the rectangular section, the maximum ratio between the sides must be ≤ 1.5.
