6.3. CONNECTING A FIREPLACE OR OPEN HEARTH TO THE FLUE

The ue gas channel is the stretch of piping which connects the product to the ue. In the connection, these simple but extremely important

principles must be respected:

• under no circumstances use a ue gas channel with a diameter less than that of the exhaust clamp with which the product is equipped;

• each metre of the horizontal stretch of the ue gas channel causes a slight loss of head which must be compensated if necessary by

elevating the ue;

• the horizontal stretch must never exceed 2 metres (UNI 10683);

200mm, pos. B, taking care to close the remaining spaces between the pipe and the ue immediately under the chimney pot pos. C.

7. AIR FLOW IN THE PLACE OF INSTALLATION DURING COMBUSTION

As the product draw their combustion air from the place of installation, it is MANDATORY that in the place itself, a sufcient quantity of air

is introduced. If windows and doors are airtight (e.g. built according to energy saving criteria), it is possible that the fresh air intake is no

longer guaranteed and this jeopardises the draught of the appliance and your health and safety. It is therefore necessary to guarantee a

supply of fresh air through an external air inlet placed near the appliance or by placing piping for combustion air which leads outside or to

a nearby airy place, with the exception of the boiler room or garage (FORBIDDEN).

IMPORTANT: For a better comfort and corresponding oxygenation of environment, the product combustion air can be directly withdrawn

at the outside. In order to do that, the stove can be connected to the external air socket by an junction (see Chap. DIMENSIONS and

Picture 9 a pagina 61).

grills and must never be blocked up. An extractor hood (suction) installed in the same room or in a neighbouring one causes a depression in

the environment. This causes the leakage of burnt gas (dense smoke, smell); it is therefore necessary to ensure a greater ow of fresh air.

The depression of an extractor hood can, in the worst case scenario, transform the ue of the product into an external air inlet,

re sucking the ue gases into the environment with very serious consequences for persons.

8. ALLOWED / NOT ALLOWED FUELS

Allowed fuels are logs. Use exclusively dry logs (max. content of water 20%). Maximum 3 logs should be loaded. The pieces of wood

should have a length of ca. 20-30 cm and a maximum circumference of 30-35 cm.

Compressed not worked-out wood briquettes must be used carefully to avoid overheating that may damage the device, since

these have a very high caloric value.

The wood used as fuel must have a humidity content lower than the 20% and must be stored in a dry place. Humid wood tends to burn

It is necessary to place this wood in a dry and ventilated place (for example under a roong) for at least two years before using it.

Besides others, it is not possible to burn: carbon, cuttings, waste of bark and panels, humid wood or wood treated with paints,

plastic materials; in this case, the warranty on the device becomes void.

Paper and cardboard must be used only to light the re.

The combustion of waste is FORBIDDEN and would even damage the appliance and the ue, causing health damages and claims by

the neighborhood owing to the bad smell. The wood is not a fuel which allows a continuous operation of the appliance, as consequence

the heating all over the night is not possible.
