TERMOCUCINOTTA EVO DSA - TERMOCUCINOTTA DSA
7093041 21
c) If the product is installed on a non totally refractory oor, one must foresee a reproof background. The oors made of inammable
material, such as moquette, parquet or cork etc., must be covered by a layer of no-inammable material, for instance ceramic, stone,
glass or steel etc. (size according to regional law). The base must extend at least 50 cm at the front and at least 30 cm at the sides, in
addition to the opening of the loading door (see Picture 5 at page 78 - B).
d) No ammable components (e.g. wall units) must be present above the product.
The Product must always operate exclusively with the ash drawer inserted. The solid combustion residues (ash) must be collected in a
sealed, re resistant container. The Product must never be on in the presence of gaseous emissions or vapours (for example glue for
linoleum, petrol etc.). Never deposit ammable materials near the Product.
During combustion, thermal energy is released which leads to considerable heating of the surfaces, doors, handles, controls, glass parts,
the ue gas pipe and possibly the front part of the appliance. Avoid contact with these elements unless using suitable protective
clothing or accessories (heat resistant gloves, control devices).
Ensure children are aware of these dangers and keep them away from the furnace when it is on.
When using the wrong fuel or one which is too damp, due to deposits present in the ue, a ue re is possible.
5.1. IN A EMERGENCY
If there is a re in the ue connection :
a) Close the loading door and the ash drawer door
b) Close the comburent air registers
c) Use carbon dioxide ( CO
2
powder ) extinguishers to put out the re
d) Request the immediate intervention of the Fire Brigade
DO NOT PUT OUT THE FIRE WITH WATER.
When the ue stops burning, have it checked by a specialist to identify any cracks or permeable points.
6. TECHNICAL DESCRIPTION
La NORDICA thermocookers are ideal for holiday ats and weekend houses or as auxiliary heating all year round.
Wooden logs are used as fuel. The appliance works as an intermittent operating appliance.
The thermocooker is composed of galvanised steel sheet plates, enamelled cast iron and thermoradiant ceramic. The furnace is found
inside the boiler made with 4 mm thick steel and reinforced with welded nails. The water from the heating system, which absorbs the heat
produced in the furnace, circulates in the boiler. Inside the furnace, there is a height-adjustable at grill (Picture 9 at page 79).
The furnace is equipped with a panoramic door with ceramic glass (resistant up to 700°C). This allows a fascinating view of the burning
ames. In addition, in this way there is no possibility of sparks or smoke escaping.
Below the oven door there is an extractable wood drawer, with the related closing door (Picture 7 at page 79 A).
ACCESSORIES
Poker Glove Height-adjustable cast iron grate
TERMOCUCINOTTA - DSA INCLUDED INCLUDED INCLUDED
TERMOCUCINOTTA EVO - DSA INCLUDED INCLUDED INCLUDED
The heating of the room takes place:
a) bymeansofradiation: through the panoramic glass and the hot external surfaces of the stove, heat is radiated into the room.
b) by conduction: through radiators or convectors in the central heating system fed by the hot water produced by the Thermocooker
itself.
The thermocooker is supplied with registers for primary and secondary air and a thermostat with which the combustion air is regulated.
1A - PRIMARY Air Register / AUTOMATIC Thermostat (Picture 7 at page 79 ).
The thermostat has the task of automatically increasing or decreasing combustion.
Dependent on the position chosen, the thermostat will act on the valve which regulates the intake of air into the furnace, placed on the
back of the cooker. Turn it in a clockwise direction from 0 to 5 to make up the re and in an anti-clockwise direction to reduce combustion.
As this is an extremely precise device, it is advisable to turn it carefully and never force the knob.
2A - SECONDARY Air Register (Picture 7 at page 79).
This register must be open (i.e. turned completely to the right), in particular for the combustion of wood (see paragraph NORMAL
OPERATION). The secondary air, passing between the double glass of the re door, heats up and triggers the dual combustion, keeping
the glass clean at the same time (register open).
To ignite the ame follow the instructions below (see Cap. IGNITION) :
• Open the buttery valve placed on the ue gas exhaust pipe must also be opened.
• Position the thermostat knob on position 5 (maximum opening).
• After having started the re with small pieces of wood and waited until it is well lit, adjust the thermostat to the positions corresponding
to the desired heat (0÷5).
• Close the buttery valve placed on the ue gas exhaust pipe must also be opened.
The register regulation necessary in order to obtain nominal caloric output is the following (see Cap. NORMAL OPERATION):
PRIMARY air SECONDARY air TERTIARY air
TERMOCUCINOTTA - DSA POS. 5 OPENED Pre-adjusted
TERMOCUCINOTTA EVO - DSA POS.4 OPENED Pre-adjusted
