La Nordica Giusy [12/32] Commissioning settings

ENGLISH

remoTe conTrol (opTional)

The heating power, the desired room temperature and the appliance ignition/switch o, can be adjusted using the remote control.

To ignite the stove, press key 1 for a few seconds; the appliance will automatically enter the ignition phase. It is possible to adjust power by

using keys 4 and 5, whereas the desired temperature can be adjusted using keys 2 and 3. To switch the stove o, press and hold key 1 for a

few seconds.

Type anD replacemenT of baTTeries

The batteries are housed in the lower part of the remote control.

To replace it remove the battery-holder (as shown in the gure

on the back of the remote control), remove or insert the battery

following the symbols on the remote control and on the battery.

For operation, 1 CR2025, 3V lithium buer battery is required.

If the remote control is o because it has no

batteries, the stove can be controlled from the

control panel on top of it.

While replacing the battery, pay attention to the

polarity by observing the symbol on the inside

compartment of the remote control.

commissioninG seTTinGs

Once the power cable at the back of the stove has been connected, move the switch, also located on the back, to (I).

The switch at the back of the stove powers the stove board.

The stove remains o and a rst screen appears on the panel

reading OFF.

mains freQuency 50/ 60hz

In the event the stove is installed in a country with 60Hz frequency, the stove will display "frequenza rete errata" ("mains frequency incorrect").

Vary the frequency as described below.

CONTROLS PROCEDURE

 Press key 5.

 Select 50 - 60Hz frequency with key 2 -3.

 Conrm using key 5 and exit the menu by pressing key 1.

THE BATTERIES USED CONTAIN METALS HARMFUL FOR THE ENVIRONMENT. THEY MUST THEREFORE BE DISPOSED OF

SEPARATELY IN APPROPRIATE CONTAINERS.
