9.1.6 Insert the new built-in grinder into the casing.

Check for the correct position of the ﬂat spring

in the built-in grinder’s spout. It has to extend

into the spout instead of laying on top of the

spout tube.

9.1.7 Connect the motor plug with the grinder and store the con-

nection well in the rear of the casing.

9.1.8 The cover of the built-in grinder is marked with two red

lines:

Red Mark 1: Basic adjustment 0, ﬁnest setting and minimum

grinding disc spacing.

Red Mark 2: Basic factory setting and also the position for instal-

ling and removing the lid, in order to achieve the factory setting

after positioning the lid.

Red Mark 1

Red Mark 2

Therefore turn the grind adjustment of the built-in grinder to the

right red mark 2 for reﬁtting the grinder’s lid.

9.1.9 Replace the grinder’s lid on the grinder and adjust to the

desired ﬁneness.

Note the correct position when lowering the lid

onto the grinder. The detent screws have to ﬁt

into the gaps. Otherwise the basic adjustment

is lost and espresso grinding is not possible any-

more.

9.1.10 Carefully lay the grinder on its side. Reassemble the three

screws under the base plate. Reposition the grinder on its rubber

feet.
