Beko FSE 21906 [11/45] Adjusting the legs
![Beko FSE 21906 [11/45] Adjusting the legs](/views2/1033578/page11/bgb.png)
EN
10
Adjusting the legs
If your freezer is unbalanced;
You can balance your freezer by
turning the front legs of it as illustrated
in the figure. The corner where the
leg exists is lowered when you turn
in the direction of black arrow and
raised when you turn in the opposite
direction. Taking help from someone to
slightly lift the freezer will facilitate this
process.
C This appliance is designed to
operate at temperatures specified
in the table below is equipped with
Advanced Electronic Temperature
Control System [AETCS] which
ensures that at the advised setting [4
- four on the knob] the frozen food in
the freezer will not defrost even if the
ambient temperature falls as low as
-15 °C.
When first installed the product
MUST NOT be placed in low ambient
temperatures because the freezer will
not reduce to it’s standard operating
temperature. Once it has reached its
steady operating state it can be re-
located.
So you may then install your appliance
in a garage or an unheated room
without having to worry about frozen
food in the freezer being spoilt.
However at low ambient temperatures
mentioned above, fridge contents are
likely to freeze, so check and consume
food in the fridge accordingly. When
the ambient temperature returns to
normal, you may change the knob
setting to suit your needs.
C If the ambient temperature is
below 0°C, the food in the fridge
compartment will freeze.So, we
recommend you don’t use the fridge
compartment in such low ambient
conditions. You can continue using the
freezer compartment as usual.
