Beko FSE 21906 [9/45] Installation
![Beko FSE 21906 [9/45] Installation](/views2/1033578/page9/bg9.png)
EN
8
3 Installation
B Please remember that the
manufacturer shall not be held liable if
the information given in the instruction
manual is not observed.
Points to be considered
when re-transporting your
freezer
1. Your freezer must be emptied and
cleaned prior to any transportation.
2. Shelves, accessories, crisper and
etc. in your freezer must be fastened
securely by adhesive tape against any
jolt before repackaging.
3. Packaging must be tied with thick
tapes and strong ropes and the
rules of transportation printed on the
package must be followed.
Please do not forget…
Every recycled material is an
indispensable source for the nature
and for our national resources.
If you wish to contribute to recycling
the packaging materials, you can
get further information from the
environmental bodies or local
authorities.
Before operating your
freezer
Before starting to use your freezer
check the following:
1. Is the interior of the freezer dry and
can the air circulate freely in the rear
of it?
2. You can install the 2 plastic wedges
as illustrated in the figure. Plastic
wedges will provide the required
distance between your freezer and
the wall in order to allow the air
circulation. (The illustrated figure is
only an example and does not match
exactly with your product.)
3. Clean the interior of the freezer as
recommended in the “Maintenance
and cleaning” section.
4. Plug the freezer into the wall outlet.
When the fridge door is open the
fridge compartment interior light will
come on.
5. You will hear a noise as the
compressor starts up. The liquid and
gases sealed within the refrigeration
system may also give rise to noise,
even if the compressor is not running
and this is quite normal.
6. Front edges of the freezer may feel
warm. This is normal. These areas
are designed to be warm to avoid
condensation.
Electric connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
• The connection must be in
compliance with national regulations.
• The power cable plug must be easily
accessible after installation.
• The specified voltage must be equal
to your mains voltage.
• Extension cables and multiway plugs
must not be used for connection.
