Compak R140 [14/21] Vibrating plate

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 18/07/2016 | K04673

1 coffee bean

100 - 300 particles

French Press

500 - 800 particles

Filter

1,000 - 3,000 particles

Mocha

3,500 particles

Espresso

15,000 - 35,000 particles

Turkish

9. VIBRATING PLATE

9.1. Vibrating plate

The grinder comes with an extension to distance the bag shaker from the machine,

allowing the possibility to use bigger bags (>0.55 lb for R80 & R100 and >1.1 lb for

R120 & R140) and therefore grinder larger amounts coffee.

To put the extension in place, remove the screw ( ) on the lower part of the bag

shaker as indicated in Fig. 7 and put the adapter in place. Reconnect the bag shaker

using the same screw.
