Compak R140 [19/21] Reset the burrs to the 0 calibration

Compak R100 [19/21] Reset the burrs to the 0 calibration

K04673 | v. 18/07/2016 | Ref. quality process 002/03 | ORIGINAL INSTRUCTIONS

11.4. Reset the burrs to the 0 / Calibration

Position 0 is the point in which the burrs no longer touch.

Following these instructions allows the user to make small adjustments to adapt the

desired particle size for each of the types of coffee referenced on the front control

knob ( ).

• Turn the front dial ( ) clockwise until the burrs are as close as possible without

touching.

• Loosen, with the help of the key wrench that comes with the grinder, the screw

( ), until the chain is released.

• Turn the front dial ( ) clockwise as far as possible.

• Tighten the screw ( ).

• Assemble the upper body ( ), tightening the two rear screws and replace the

hopper.
