ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 06/09/2016 | K06307
8
7.3. Where to use
The grinder should be installed on a at, stable surface. The minimum
dimensions of the work space should be as follows:
Model
E5
E6 OD, E8 OD,
E10 CONIC OD
E10 MASTER
CONIC OD
Height
20.27
515
25.78
655
27.55
700
in
mm
Width
7.08
180
9.25
235
9.25
235
in
mm
Depth
15.55
395
16.53
420
16.53
420
in
mm
7.4. Grinder installation
Before grinder installation, the following should be considered:
• The grinder information plaque data coincides with the electrical system on
site.
• The electrical outlet coincides with the grinder plug.
• The electric power at the location of installation should meet the minimum
required to properly run the grinder.
• The installation site should have the proper electrical overload protections.
• The grinder should be properly grounded as specied by local code.
NOTE: The grinder should be used in environments with mínimum temperature
of 77-86F and should not be installed in places (such as industrial kitchens) where
cleaning is done with direct water spray cleaning.
