8.2. Grinder up set

Place the hopper ( ) on the grind regulator ( ) and make sure the bean trap ( )

is in the closed position. Lock the hopper ( ) in place using a at head screw driver

to gently tighten the hopper security screw making it match to the hole at the bean

hopper collar ( ) (Fig. 2).

Remove the hopper lid ( ), ll the hopper with coffee ( ), and replace the lid on the

hopper ( ) (Fig. 3).

Plug in the grinder, and place the main power switch ( ) I - 1 AUTOMATIC / 0 - 0 OFF /

II - 2 MANUAL, AUTOMATIC / OFF / MANUAL or I / OFF / II to position I - 1 AUTOMATIC

, I or AUTOMATIC and open the bean trap ( ) to allow coffee to pass into the grind

chamber.

8.3. Grind adjustment system

8.3.1. Parallel micrometrical system

Rotate the grind regulator ( ) until reaching the grind level desired.

Rotating the grind regulator clockwise will result in a courser grind; turning the

regulator counter clockwise will result in a ner grinder* (Fig. 4).

Once you reach the desired grinding point, you can x the grinding regulation ( )

using the regulation break ( ) (Fig. 5).
