Menumaster JET519V2 [6/15] Display and features
![Menumaster JET519V2 [6/15] Display and features](/views2/1336117/page6/bg6.png)
6
Display and Features (cont’d)
Start pad
The Start pad is used
to begin a manual time
entry cooking cycle.
Temperature warnings
The combination oven has two
distinct temperature warnings.
Warnings sound with a three beep
signal when a programmed pad is
pressed. Warnings are:
• A warning when the preheat
temperature does not match the
preprogrammed temperature of
a cooking condition.
• A warning when the actual
oven cavity temperature is
not to preheat temperature,
such as when the oven is rst
started.
To override the warning and begin
a cooking cycle, press the Start
pad. To turn off warnings, see
User Options section.
Stop/Reset pad
The Stop/Reset pad
stops a cooking
sequence in progress,
clears out any remaining time,
and also ends a programming
or user option cycle. When the
Stop/Reset pad is used to end a
programming or option change,
the changes are discarded.
Cooking Display
DISPLAYS DESCRIPTION
OVEN PREHEATING
475°F
Oven Preheating 475°F or 250°C displays
when oven is turned on and is warming up to the
selected preheat temperature. Oven Preheating
also ashes when a cooking condition can be
started or programmed.
READY
475°F
Ready 475°F or 250°C displays when oven has
reached preheat temperature and is ready to cook.
Ready also ashes when a cooking condition can
be started or programmed.
Note: Oven will shutdown after two hours of
inactivity.
00:00
Displays cooking time. If stage cooking is
programmed, total cooking time is displayed
.
MW 50%
MW 50% displays the current microwave power
level. 100% is the highest setting, and 0% is lowest
(no microwave energy used).
ITEM-05
ITEM-05 displays the single or double digit entry
of a programmed cooking condition when using a
programmed pad.
STAGE 1
Stage 1 displays the stage number (1 through 4)
the oven is at in the cooking condition
.
STANDBY
STANDBY displays when oven is turned off,
and also after the oven is plugged in, the door is
opened, and then shut.
Programming Display
DISPLAYS DESCRIPTION
Enter Program
to Add/Review:
Displays when oven is in programming mode for
single digit or double digit memory.
STAGE 1
Displays stage number during cooking or when
programming a specic cooking stage. Stage
number (1 through 4) indicates the stage that is
being used.
USB Display
DISPLAYS DESCRIPTION
USB
Displays when keypad 5 is pressed and held and
transfer to or from USB ash drive is ready
