Hytera PD-705G [11/22] Assembling the accessories

Assembling the Accessories

Attaching the Antenna

Turn the antenna clockwise to fasten it.

To remove the antenna, rotate it counter-clockwise.

Attaching the Battery

1. Insert the battery into top of the radio. See arrow

①

2. Slightly press the bottom of the battery until a click is heard.

See arrow

②

To remove the battery, turn off the radio rst. Then slide the battery

latch upwards to unlock the battery.

Attaching the Belt Clip

1. Remove the screws.

2. Align the screw holes on the belt clip with those on the radio’s

body, and then tighten the screws.

To remove the belt clip, loosen the screws.

Attaching the Audio Accessory/Programming

Cable

1. Open the accessory jack cover as the arrow shown.

2. Align the plug with the accessory jack.

3. Tighten the screw on the plug.

To remove accessories, loosen the screw.

Caution: When you are using an external accessory,

waterproof performance of the radio may get

affected.

Before Use
