BEST K 508L [3/28] Operation

bracket (A) to the wall using the 2 holes (B) just made – Fig. 7 - (the bracket retaining screws are provided). Use

the 2 triangles cut into the bracket to position it exactly along the vertical axis of the hood.

3. Fasten the bracket to the ceiling or the wall in such a way that it is in line with your hood (Fig. 9).

4. If the slots in the hood are NOT obstructed by the wall units (Fig. 2), proceed as follows:

- Fold the 2 tabs of the ceiling bracket inward (Fig. 12).

- Slide out the upper flue and position it with the slots facing up (Fig. 13).

- Fit the flange on the baffle (Fig. 14) and connect a flexible hose to it, locking it with a metal clamp (flange, baffle

and clamp are not provided).

- Fit the baffle from the front (slightly diagonal) and secure it to the ceiling bracket with 2 screws (Fig. 15).

7. If the slots in the hood are NOT obstructed by the wall units (Fig. 2), proceed as follows:

- Connect a flexible hose to the air vent of the hood and lock it with a metal clamp (hose and clamp not provided).

8. Make the electrical connection of the hood using the power cable (Fig. 16).

9. Raise the upper flue up to the ceiling and secure it with 2 screws (Fig.11).

10. Install the charcoal filter sliding the two filter clips into their seats (Fig. 17) and turn it upwards.

OPERATION

sets hour metering when the Filter Alarm is active (motor OFF).

FILTER ALARM: Displayed for 30" when the motor is off:

After 30h of operation, the central segment lights up on the display; It indicates that the grease filters need to be cleaned.

After 120h of operation, the central segment flashes on the display; It indicates that the grease filters need to be cleaned

and the charcoal filters replaced.

After cleaning the grease filters (and/or replacing the charcoal filters), restart the hour counter (RESET) by pressing

the key E during display of the filter alarm.

CONTROLS shown in Fig. 19:

Remove the grease filters as follows, depending on the model.

Model shown in Figure 20: remove the metal panel by pressing at the points indicated by the arrows; then rotate the

panel so that the right-hand pin slips out of its seat (A); move the panel to the right until the left-hand pin slips out

of its seat. Then remove the grease filter (Fig. 21): press the retainer near the handle inwards and then pull the filter

downwards. Wash the metal panel and the grease filter with neutral detergent.

Model shown in Figure 22: press the retainer near the handle inwards and then pull the filters downwards.

If the model you have purchased has the controls shown in Figure 18, clean the grease filters when the Filter Alarm

grease filters on average every 2 months depending on use.

Charcoal filters : using the appliance as a filtering version requires the replacement of the charcoal filters at regular
