BEST Strip черная [16/64] English

English

! The appliance must be installed by a qualified person

in compliance with the instructions provided.

Wear gloves when carrying out installation and

maintenance operations.

If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

Warning: Failure to install the screws or fixing device in

accordance with these instructions may result in

electrical hazards.

The hood can look different to that illustrated in the

drawings in this booklet. The instructions for use,

maintenance and installation, however, remain the

same.

- Only for hoods equipped with electronic control of

Fig.24-25-26:

The 4th speed (intensive) is automatically lowered to 3rd

speed after 5 minutes of operation to optimise energy

consumption.

- Only for hoods equipped with electronic control of

Fig.27: In order to optimize energy consumption, high

speed of work signaled by red LEDs (L) will be

automatically reduced to standard speed after 5 minutes

of work.

- If the hood is left on (lights and/or motor), after 10

hours in the absence of commands from the user, it will

automatically switch to OFF condition with all services

switched off.

- The Buzzer emits a “beep” each time that a command

is set from the keyboard or remote control (optional).

- In the event of interruption of power during the hood, if

you restore the hood in the OFF state, then the engine

must be reactivate manually.

AIR VENT

(for ducting versions)

! Prepare the hole and the air vent duct (150 mm

diameter).

! Use a duct of the minimum indispensible length.

! Use a duct with as few elbows as possible (maximum

elbow angle: 90°).

! Avoid drastic changes in the duct cross-section.

! Use a duct with an as smooth as possible inside.

! The duct must be made of certified material.

! Do not connect the hood to smoke exhaust ducts for

the products of combustion (boilers, fireplaces,

stoves, etc).

! For the air vents comply with the provisions laid down

by the competent authorities.

In addition, the air must not be evacuated through a

hole in the wall unless specifically intended for this

purpose.

! Fit air intakes in the room to prevent the hood from

creating a negative pressure in the room (which must

not exceed 0.04 mbar); if the hood is used at the same

time as non-electrical equipment (gas-, oil- and

charcoal-fired stoves, etc.) the exhaust gas may be

sucked in by the heat source.

FILTERING OR DUCTING VERSION ?

The hood may be in filtering or in ducting version.

Decide from the outset which type is to be installed.

For better efficiency, we recommend installing the hood

in the ducting version (if possible).

Ducting version

Version with external motor

The hood purifies the air and evacuates it to the outside

through an exhaust duct (diameter 150 mm).

Filtering version

The hood purifies the air and recycles the clean air back

into the room.

CONTROLS

CONTROLS Fig.24:

P1: Filter alarm reset

P2: LED on/off - (only certain models: holding the button

down you can change the LED intensity to High or

Low).

Note: LED activation is displayed by P2 only when

the lift panel is completely open.

P3: Motor on/off - 1st speed

P4: 2nd speed

P5: 3rd speed

P6: 4th speed

P7: Lift panel up/down (during opening the panel can be

stopped at the desired height by pressing the

button a second time).

5' Timer function:

Holding the buttons P3, P4, P5 or P6 pressed down

(>2") the 5' Timer function is activated. When the time

has run out, the motor turns off and the lift closes. The

LEDs change from High to Low intensity. When the

function is active, the LED corresponding to the current

motor speed blinks.

Filter alarm display:

Grease filters: After 30h of motor operation, the LED of

the P1 button comes on for 30'' every time the motor

turns off.

Charcoal filter: After 120h of motor operation, the LED of

the P1 button blinks for 30'' every time the motor turns

off.

CONTROLS Fig.25:

P1: Filter alarm reset

P2: Motor on/off - 1st speed

P3: 2nd speed

P4: 3rd speed

P5: 4th speed

P6: Lift panel up/down (during opening the panel can be

stopped at the desired height by pressing the
