IS517
Page 10
279
279
C/L
47
75
390
152
196
558
390
750
1000
1250
65
420
565
50
25
750 Models
1000 Models
1250 Models
210
FRONT OF COUNTER / CUSTOMER SIDE
750 Models
BACK OF COUNTER / FOOD SERVICE SIDE
Details of the base section and cabinet (1)
Details of cut-out for refrigeration module (2)
