![Lincat C6R/100SU [5/20] Features](/views2/1337455/page5/bg5.png)
IS517
Page 5
FEATURES
PRODUCT SPECIFICATION
TECHNICAL SPECIFICATION
650 Range Refrigerated Merchandiser – C6R/75, C6R/100, C6R/105,
C6R/125, C6R/130
D6R/100, D6R/125
500 Range Refrigerated Merchandiser – D5R/100, D5R/125
350 Range Refrigerated Merchandiser – D3R/100
Fan-assisted refrigeration
Double glazed glass (flat panels)
Electronic control
Hot gas automatic defrost
Sliding rear doors (double glazed)
Independently switchable light
Adjustable shelf positions (back
service models only)
230 Volt, 50 Hz, single phase
Model C6R/75 C6R/100 C6R/105 C6R/125 C6R/130
Max. Operating
Temperature
O
C
25
Internal volume litres
226.6 306.4 226.6 386.2 306.4
Internal dims cm 710x570x560
960x570x560
710x570x560
1210x570x560
960x570x560
Width mm
750 1000 1050 1250 1300
Depth mm
650 650 650 650 650
Height mm
755 755 755 755 755
Power Rating watt
602 717 604 729 717
Weight kg 89.5 117 105 137.5 112.2
Refrigerant R404a
Model D3R/100 D5R/100 D5R/125 D6R/75 D6R/100 D6R/125
Max. Operating
Temperature
O
C
25
Internal volume litres
85.8 127.3 172.2 226.6 306.4 386.2
Internal dims cm 710x310x390
710x460x390
960x460x390
710x570x560
960x570x560
1210x570x560
Width mm
1000 1000 1250 750 1000 1250
Depth mm
350 500 500 650 650 650
Height mm
575 575 575 965 965 965
Power Rating watt
393 602 621 602 717 729
Weight kg 68 84 100 95 123 149.5
Refrigerant R404a
