USER INSTRUCTION

APPLIANCE USE

This appliance is only for professional use and should only be used by qualified personnel.

Ensure that the person responsible understands how to light, safely operate, clean and shutdown the

appliance and is made aware of the position and operation of the gas isolating cock in the event of an

emergency.

HEAT TRANSFER PROFILE SEATING

Ensure that the heat transfer

profiles (H) are clean and

correctly seated.

The support bracket (F) faces

toward the front of the appliance

To correctly position the heat transfer channels, hook the short edge beneath the location point on the support

brackets and lower into place.

To remove them for cleaning, grip longest edge and twist out.

Always replace the channels as shown.

LIGHTING SEQUENCE

 Open the main gas cock.

 Push in the control knob then rotate anti-clockwise to any position to allow gas through to the

burner. Manually light this burner using a taper or piezo ignitor wand through the aperture in

the fascia panel. Do not attempt to light the gas through the heat transfer channels.

 On establishing a flame at the burner, keep the knob depressed for approximately 15 seconds

then release. The burner should remain lit.

 Repeat for the other burner.

SHUT DOWN

To shut down the appliance rotate all control knobs clockwise to the OFF position. The gas supply

stopcock or bottle valve should now be closed.

CLEANING

Ensure the appliance is cool and the gas supply is isolated before commencing cleaning.

After use wash the unit down with a warm detergent solution.

 Any accumulated fats or grease on internal parts and collecting pans from previous

cooking should be routinely cleaned prior to use to prevent the risk of fire.

 The cooking grid may be cleaned using a wire brush to remove carbon deposits. It is

recommended that suitable eye and hand protection be worn.

Do not use abrasives on stainless steel parts.

Do not use any products containing chlorine or hydrochloric acid to clean stainless steel

surfaces.

Do not clean the appliance using a water jet.
