SERVICING

SERVICE ACCESS

To access and service the gas control valves

 Remove the control knobs and fascia panel to gain access to the valves.

 Remove the two screws securing the valve boss and carefully withdraw the spindle

from the valve.

 Grease as necessary and refit parts. Carry out gas soundness check.

FASCIA PANEL REMOVAL

 Remove the debris drawer (A) and fat tray (B).

 Remove the control knobs (C).

 Remove the screws left and right on the

underside of the fascia panel (D). Tilt the fascia

panel from the bottom up and lift clear of the

hob top.

OPERATIONAL CHECK

Commissioning must include an operational check of all controls.

 Check that each burner can be lit at both full rate and low rate.

 Check that each burner will remain lit when turned to low rate.
