INSTALLATION

SITING

• The installer must ensure that all regulations are met and that there is an

unobstructed minimum distance of 1000mm from the top of the flue to the ceiling,

which must be of non-combustible material.

• Where install under an extraction canopy then the minimum clearance must be

500mm between the flue top and the extraction filters.

• The appliance should be installed on a level surface ensuring the unit is stable and

firmly located.

• Any partitions, walls or kitchen furniture in close proximity must be of non-

combustible materials and not be closer than 50mm from the sides and rear of the

flue.

• From the front of the appliance the minimum safe distance for combustible materials

shall be not less than 750mm

The appliance must not be installed directly above any other cooking equipment.

GAS SUPPLY AND CONNECTION

• Connection is at the rear of the unit via a R½ male thread.

• Connection shall comply with local regulations.

• The hose shall be periodically examined and replaced as necessary.

• When making the connection to the appliance an isolating cock should be fitted into

the supply line close to the unit, for emergency shutdown or servicing purposes.

SUPPLY PRESSURES

• The Salamander grills are un-governed appliances and connect directly to the

relevant gas supply. See above table for inlet pressures.

• If necessary to gain access to the gas pressure test nipple remove the access panel

on the right hand side of the appliance. The nipple is situated fitted to the top of the

valve manifold.

• Remove the blanking screw and attach a pressure gauge to the boss of the test

nipple and check inlet pressure.

ACCESSORIES

A bench stand (GR3/BS, GR7/BS), wall shelf (GR3/WS, GR7/WS) and floor stand

(GR3/FS, GR7/FS) are optional accessories available for these units. Should an alternative

to these accessories be used, please ensure that the mounting is stable and of a non-

combustible material.

A branding plate and drip tray for the GR3 model are available as an accessory part

number APB03.

INSTRUCTION TO USER

Ensure that the person responsible understands how to light, safely operate, clean and

shutdown the appliance and is made aware of the position and operation of the gas

isolating cock in the event of an emergency.
