Lincat HT6nFL [14/16] Spare parts list
![Lincat HT6pFL [14/16] Spare parts list](/views2/1337678/page14/bge.png)
IS 513 ECN 3706 Page 14 of 16
Part number
Part description
Used on
BU07 Burner Body All
BU08 Burner Head All
BU09 Burner Cap All
TC01 Thermocouple All
FAS351 Burner Gasket All
JE155 Natural Gas Injector All
JE156 Propane Gas Injector All
JE157 Butane Gas Injector All
PA25 Pan Support All
MA140 Manifold HT3
MA141 Manifold HT6
MA141 Manifold HT9
VA10 Valve All
BU158 VA10 Tube Nut All
BU159 VA10 Olive All
BU208 VA10 Clamp Bracket All
BU209 VA10 Clamp Screw All
KN196 Control Knob All
CO15 Compression Fitting All
TU13601 Front Burner Pipe All
TU13602 Rear Burner Pipe All
