Lincat J10nFL [11/17] J5 j10 general service
![Lincat J10nFL [11/17] J5 j10 general service](/views2/1337693/page11/bgb.png)
11
SERVICING
Gas catering equipment should be routinely serviced to ensure a long trouble-free life. With this in
mind it is recommended that the appliances are serviced every 6 months by a competent gas engineer.
Please see page 17 “Service” for information on authorised service agents.
(J5 & J10 General service).
1. Carry out a general check of the installation paying particular attention to the following:-
has the unit been installed using the correct hose?
does the unit have a safety chain?
does the equipment have a separate isolation valve?
2. Check all components for correct operation and replace where necessary, following the
appropriate instructions.
3. Visually check the burner operation, closely observing the flame picture and look for evidence of
any debris or damage. Remove burner and clean or replace as necessary.
4. Visually check the injectors and replace or clean as necessary (Clean using a brush with nylon
bristles or similar). Avoid using metal reamers or wire as this may damage or increase the orifice
size.
5. Check the burner pressure and adjust where necessary with the unit in full operation, at the test
nipple located on the burner. See “Installation Instructions”- “Pressure Setting” for information.
6. Check operation of the limit thermostat.
7. Clean pilot assembly and check that it is burning cleanly.
8. Check the alignment of the spark electrode and thermocouple within the pilot assembly. Adjust if
necessary.
9. Ensure that the flue is clear.
10. Carry out a gas soundness check.
