FOREWORD
Thank you for buying this Lincat product, which we hope will give you years of trouble free service.
To ensure you receive the maximum benefit from your new fryer please take the time to read this
instruction book carefully, following any directions given.
We manufacture over 300 different items of catering equipment and are constantly adding to and
improving the range.
If you‟re thinking of extending your kitchen or renewing a catering appliance in the near future, see
our sales brochures available from your local distributor or send for one direct from us before you
make your decision.
IMPORTANT
Please read this page carefully before initially using the equipment.
WARNING
This appliance must be installed and serviced by a registered engineer.
Whilst in operation, parts of the catering equipment will become hot. Suitable precautions must be taken to
avoid accidental burns, therefore the appliance should be positioned to minimise the possibility of accidental
touching.
This appliance is for professional use and shall be operated by qualified personnel.
CONSEQUENTIAL LOSS
Lincat do not accept any responsibility for loss of food, production time, profit, etc., which may result from
a break-down of the equipment
MAINTENANCE
1) These units must not be cleaned using a water jet.
2) Clean units with water and detergent - do not use abrasives.
