7
ENGLISH
Potable Water
Inlet G3/4
Inlet Hose
Drain Outlet R3/4
Outlet Hose
Cooling Water
Inlet Rc1/2
Cooling Water
Outlet Rc1/2
1/2-3/4 Nipple
Condenser Cooling Circuit
Water-Cooled Model [a]
[a] Standard connections according to WRAS regulations in U.K.
*Whenselectingacoolingtower,refertothefollowingpeakvaluesofheatowinthecondenser:
Model IM-30CW/45W: 295 - 760W
IM-65W: 875W
IM-100/130W: 1165W
IM-240W: 5235W
* Pipes between the cooling tower and the icemaker should be at least 20 mm DIA to reduce pressure loss, even though the
icemakerttingsare13mmDIA.
* Pressure loss in the water circuit inside the unit will be 5 to 6 m
whenthecoolingwaterowsattheratioof4to5lit/min.
* Select a circulating pump referring to the above values of heat
ow.
* Do not use a cascade pump, or the water regulator will vary the
owandstopitduringthedefrostcycle.
[Icemaker Connections]
1) Attach the angled end of flexible inlet hose (accessory) to the
G3/4 fitting on the rear of the icemaker as indicated, ensuring
rubber sealing washer is correctly positioned. Hand tighten
sufcientlytoprovideleakfreejoint.
2) Attach the other end of inlet hose to the water tap, noting washer
is correctly positioned before hand tightening as above.
Note:Ifltrationortreatmentisused,ensureicemakersection
only is on treated water supply, not the condenser.
3)Attachgreyexibleoutlethose(accessory)totheR3/4ttingon
therearoftheicemakerasindicated,conrmingtmentofrubber
washerbeforenallyhandtighteningthejoint.Thehosecanbe
cut to length as necessary to suit position of main drain.
4) By means of a suitable spanner or wrench, tighten the 1/2-
3/4nipples(accessory)intotheRc1/2ttingsontherearofthe
icemaker as indicated. P.T.F.E. tape and/or a suitable sealing
compound should be used to obtain a leak free joint.
Note: Jointing compounds should be approved and suitable for
potable water use.
5) Connect the condenser cooling circuit to the free end of 1/2-3/4
nipples as indicated using a suitable rigid type pipe.
[b] Connections according to regulations other than WRAS by utilising accessory hoses
1) Follow the instructions from 1) to 4) in [a] above.
2) For condenser connections, use supplied accessory hoses and make the same connections as 1) to 3) in [a] above to the free
end of 1/2-3/4 nipples as indicated.
Icemaker Cooling
Tower
Flow Control Valve
Strainer Pump
P
