6
ENGLISH
-Changetothe“fulldrainush”modeisrecommended.ContactyourlocalHoshizakiserviceagent.
* Water supply pressure should be minimum 0.07 MPa (0.7 bar) and maximum 0.78 MPa (8 bar). If the pressure exceeds 0.78
MPa (8 bar), use a proper pressure reducing valve. Do NOT throttle back the supply tap.
* A plumbing permit and services of a licensed plumber may be required in some areas.
*Theicemakerdrainisgravityow,soensuredrainhosehasanadequatepitchorfall.
* Drain lines should not be installed directly to the sewer system. A vertical air gap of a minimum of 5
cmshouldbebetweentheendofthedrainhosesfromtheicemakerandtheoordrain.
* Topreventabackowintothestoragebin,theoutlethosemustbelaidasshown.
*Onwater-cooledmodel,abackowpreventermayberequiredinthecoolingwatercircuit.
* Be sure to use the new hose-sets supplied with the appliance. Do not reuse any old hose-sets.
[Air-Cooled Model]
1) Attach the angled end of flexible inlet hose
(accessory)totheG3/4ttingontherearofthe
icemaker as indicated, ensuring rubber sealing
washer is correctly positioned. Hand tighten
sufcientlytoprovideleakfreejoint.
2) Attach the other end of inlet hose to the water
tap, noting washer is correctly positioned before
hand tightening as above. It is a wise precaution
to have a stop valve within easy reach.
3) [Except IM-100CNE]
Handtightengreyexibleoutlethose(accessory)
ontotheR3/4ttingontherearoftheicemaker
as indicated, ensuring rubber washer is correctly
positioned to obtain a leak free joint. The hose
can be cut to length as necessary to suit position
of main drain.
[IM-100CNE]
Bymeansofasuitablespannerorwrench,tightenthe3/4-3/4nipple(accessory)intotheRc3/4ttingonthebottomofthe
icemaker as indicated. P.T.F.E. tape and/or a suitable sealing compound should be used to obtain a leak free joint.
Note: Jointing compounds should be approved and suitable for potable water use.
Handtightengreyexibleoutlethose(accessory)ontothe3/4-3/4nippleasindicated,ensuringrubberwasheriscorrectly
positioned to obtain a leak free joint. The hose can be cut to length as necessary to suit position of main drain.
[Water-Cooled Model]
* Hoshizaki recommends that the water-cooled condenser should be connected to a closed circuit recirculating type cooling
system utilizing a tower, water chiller or similar. Water make up should be via a ball valve/break tank arrangement.
* Whilst connecting a water-cooled condenser to a mains water (potable) supply will not affect the performance of the machine,
it will most certainly cause a high use/waste of a valuable resource and is not recommended.
* The services of a licensed or coded plumber should be used to ensure a correct installation.
* The connections should be made properly in compliance with the applicable national or local regulations.
Water Supply Tap
Inlet Hose
Potable Water
Inlet G3/4
Inlet Hose
Drain Outlet R3/4
Outlet Hose
Air-Cooled Model
Downgrade
GOOD BAD
Upgrade
BAD
IM-100CNE
Drain Outlet Rc3/4
Outlet Hose
3/4-3/4 Nipple
5cm air gap
Drain
Floor
