ILLUSTRATED PARTS LIST IP73
WB2, ILLUSTRATED PARTS/RECOMMENDED PARTS 042817NC
ITEM # PART # DESCRIPTION
1 WC-1902-101 SHANK, FAUCET PLAIN ASSY
2 WC-58400 COVER, TOP
3 WC-1408 CORD GRIP, 7/8” O.D.
4A WC-1200
1
CORD, 14/3 SJTO 6’ BLK W/PLUG
4B WC-1203-103
2
CORD, 16A SJT 6’ BLK W/CONNECTORS
CAFE POUR OVER EXPORT
5 WC-608-101
CONTROL BOARD, LIQUID LEVEL
120/240VAC
6 WC-2401K KIT, ELBOW 3/8 NPT X 1/4 FLARE
7A WC-826L
1
VALVE, INLET 1 GPM 120V 9W
7B WC-856
2
VALVE, INLET 1 GPM 240V 6W
8 WC-66039 PAN, DRIP TRAY PLASTIC DTP-08
9 WC-66042 SCREEN, DRIP TRAY 3.85” x 7.7”
10 WC-1813
WASHER, 1-1/8” OD ETHYLENE
PROPYLENE RUBBER
ITEM # PART # DESCRIPTION
11A WC-102
1
SWITCH, TOGGLE NON-LIT SPST 15A
125/6A 250VAC RESISTIVE
11B WC-103
2
SWITCH, TOGGLE NON-LIT DPST 25A
125/250VAC RESISTIVE
12 WC-3503 LEG, 3/8”-16 STUD SCREW BUMPER
13 WC-1800HWK
KIT, FAUCET ASSY, RED HANDLE 1-1/32-14
UNS CURTIS
14 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
15 WC-5231 COMPOUND, SILICONE 5 OZ
16 WC-13488 HARNESS ASSY, WB2A10
17 WC-504
THERMOSTAT, CAPILLARY SPST 250V
25A GEM
18 WC-2948 FITTING, TANK OVERFLOW 304SST
19 WC-4212 NUT, 5/8-18 JAM UNF SS
20 DTP-08 DRIP TRAY, ASSY PLASTIC 8”
WB2A10/30 - Main Chassis - Parts List
ITEM # PART # DESCRIPTION
5 WC-608-101
CONTROL BOARD, LIQUID LEVEL
120/240VAC
7 WC-826L VALVE, INLET 1 GPM 120V 9W
12 WC-3503 LEG, 3/8”-16 STUD SCREW BUMPER
ITEM # PART # DESCRIPTION
14 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
17 WC-504
THERMOSTAT, CAPILLARY SPST 250V 25A
GEM
Recommended Parts to Stock
1
WB2A10,
2
WB2A30
